| Part No | Wire Size (Metric) | Thread (UNF) | Fully Open (MM) | Fully Closed (MM) | Toggle Width (MM) | Toggle Pin (MM) |
|---|---|---|---|---|---|---|
| B22-03 | 3 MM | 1/4″ | 231.0 | 155.0 | 6.4 | 6.4 |
| B22-144 | 4 MM | 1/4″ | 231.0 | 155.0 | 6.4 | 6.5 |
| B22-04 | 4 MM | 5/16″ | 252.0 | 169.0 | 8.4 | 7.9 |
| B22-5165 | 5 MM | 5/16″ | 254.0 | 171.0 | 8.4 | 7.9 |
| B22-05 | 5 MM | 3/8″ | 282.0 | 190.0 | 9.9 | 9.5 |
| B22-386 | 6 MM | 3/8″ | 283.0 | 191.0 | 9.9 | 9.5 |
| B22-06 | 6 MM | 7/16″ | 313.0 | 213.0 | 11.5 | 11.1 |
| B22-7167 | 7 MM | 7/16″ | 316.0 | 216.0 | 11.5 | 11.1 |
| B22-07 | 7 MM | 1/2″ | 339.0 | 235.0 | 13.1 | 12.7 |
| B22-08 | 8 MM | 1/2″ | 339.0 | 235.0 | 13.1 | 12.7 |
| B22-588 | 8 MM | 5/8″ | 402.0 | 276.0 | 16.3 | 16.0 |
| B22-10 | 10 MM | 5/8″ | 402.0 | 276.0 | 16.3 | 16.0 |
| B22-12 | 12 MM | 3/4″ | 521.0 | 353.0 | 19.1 | 18.5 |
